Type |
Digital, single-lens reflex, AF/AE camera |
Recording media |
Type I or II CF card, UDMA mode 7-compatible * Dual CF card slots |
Image sensor size |
Approx. 36 x 24mm |
Compatible lenses |
Canon EF lenses (except EF-S lenses) (35 mm-equivalent lens focal length will be as indicated on the lens) |
Lens mount |
Canon EF mount |
|
|
Type |
CMOS sensor |
Effective pixels |
Approx. 18.10 megapixels |
Aspect ratio |
3:2 |
Dust delete feature |
Auto, manual, dust delete data appending |
|
|
Recording format |
Design rule for Camera File System 2.0 |
Image type |
JPEG, RAW (14-bit Canon original), RAW+JPEG simultaneous recording enabled |
Recorded pixels |
L (Large) |
Approx. 17.90 megapixels (5184 x 3456) |
M1 (Medium1) |
Approx. 14.20 megapixels (4608 x 3072) |
M2 (Medium2) |
Approx. 8.00 megapixels (3456 x 2304) |
S (Small) |
Approx. 4.50 megapixels (2592 x 1728) |
RAW |
Approx. 17.90 megapixels (5184 x 3456) |
M-RAW |
Approx. 10.10 megapixels (3888 x 2592) |
S-RAW |
Approx. 4.50 megapixels (2592 x 1728) |
JPEG quality |
10 levels |
Recording function |
Standard, Auto switch card, Record separately, Record to multiple |
Create / select a folder |
Possible |
File name |
Preset code, User setting 1, User setting 2 |
File numbering |
Continuous, Auto reset, Manual reset |
|
|
Picture Style |
Auto, Standard, Portrait, Landscape, Neutral, Faithful, Monochrome, User Def. 1 - 3 |
White balance |
Auto, Preset (Daylight, Shade, Cloudy, Tungsten light, White fluorescent light, Flash), Custom, Color temperature setting (Approx. 2500-10000K), Personal white balance (5 settings), White balance correction and White balance bracketing possible * Flash color temperature information transmission enabled |
Noise reduction |
Applicable to long exposures and high ISO speed shots |
Automatic image brightness correction |
Auto lighting optimizer |
Highlight tone priority |
Provided |
Lens aberration correction |
Peripheral illumination correction, chromatic aberration correction |
|
|
Type |
Eye-level pentaprism |
Coverage |
Vertical / horizontal approx. 100% (with eye point approx. 20mm) |
Magnification |
Approx. 0.76x (-1m-1 with 50mm lens at infinity) |
Eyepoint |
Approx. 20mm (from eyepiece lens center at -1m-1) |
Built-in dioptric adjustment |
Approx. -3.0 - +1.0m-1 (dpt) |
Eyepiece shutter |
Built-in |
Focusing screen |
Ec-C V provided, interchangeable |
AF status indicator |
Provided |
Grid display |
Provided |
Electronic level |
Horizontal: |
1° increments, ±6° |
Vertical: |
1° increments, ±4° |
* During horizontal shooting |
Mirror |
Quick-return type |
Depth-of-field preview |
Provided |
|
|
Type |
TTL secondary image-registration, phase detection |
AF points |
61 points (Up to 41 cross-type points) * Number of available AF points and cross-type points vary depending on the lens. |
Focusing brightness range |
EV -2 – 18 (with center f/2.8 AF point, at 23°C / 73°F, ISO 100) |
Focus modes |
One-Shot AF, AI Servo AF, Manual focusing (MF) |
AF area selection modes |
Single-point Spot AF (manual selection), Single-point AF (manual selection), AF point expansion (manual selection; up, down, left and right), AF point expansion (manual selection; surround), Zone AF (manual selection), Auto selection of 61 AF points |
AF point automatic selection conditions |
Depending on EOS iTR AF setting (AF using color and face detection information possible) *iTR: Intelligent Tracking and Recognition |
AF Configuration tool |
Case 1 - 6 |
AI Servo characteristics |
Tracking sensitivity, Acceleration / deceleration tracking, AF point auto switching |
AF fine adjustment |
AF Microadjustment (All lenses by same amount or Adjust by lens) |
AF-assist beam |
Emitted by the EOS-dedicated external Speedlite |
|
|
Metering modes |
Approx. 100,000-pixel RGB metering sensor and 252-zone TTL metering at max. aperture EOS iSA (Intelligent Subject Analysis) system • Evaluative metering (linked to all AF points) • Center-weighted average metering |
Metering Range |
EV 0 - 20 (at 23°C / 73°F with EF50mm f/1.4 USM lens, ISO 100) |
Exposure control |
Program AE, Shutter-priority AE, Aperture-priority AE, Manual exposure, Bulb exposure |
ISO speed (recommended exposure index) |
Auto ISO, manually settable within ISO 100 – 51200 (1/3-stop or whole-stop increments) and expandable to L (ISO 50), H1 (ISO 102400), H2 (ISO 204800) |
ISO speed settings |
ISO speed range, Auto ISO range and Auto ISO minimum shutter speed settable |
Exposure compensation |
Manual |
±5 stops in 1/3- or 1/2-stop increments |
AEB |
±3 stops in 1/3- or 1/2-stop increments (Can be combined with manual exposure compensation) |
AE lock |
Auto |
Applied in One-Shot AF mode with evaluative metering when focus is achieved |
Manual |
By AE lock button |
Standard exposure level adjustment |
AE microadjustment possible |
|
