Printer Type |
6-Color 44-inch Printer |
Number of Nozzles |
Total: 15,360 C, M, Y, BK, MBK, R: 2,560 nozzles each |
Nozzle Pitch |
1,200 dpi Non-firing nozzle detection and compensation |
Print Resolution (Up to) |
2,400 x 1,200 dpi (Max) |
OS Compatibility |
Windows® (XP/Vista/7/8), Macintosh® (OSX) |
Standard Interfaces |
USB 2.0 High-Speed 10/100 Base-T/TX |
Ink Droplet Size |
4 picoliter |
Ink Capacity |
330 and 700ml per color available |
Ink Droplet Size |
LUCIA EX Ink (Pigment based) |
Color Set |
Cyan, Magenta, Yellow, Black, Matte Black, Red |
Buffer Ram |
384 MB |
Media Width |
Cut Sheet: 8" - 44" Roll: 10" - 44" |
Media Thickness |
Front Loading Manual Feed: 0.07 - 0.8mm (2.8 - 31.4mil) Roll: 0.07 - 0.8mm (2.8 - 31.4mil) |
Maximum Roll Print Length |
59 Feet (18 meters)2 |
Maximum Media Roll Diameter |
5.9" (150mm) |
Borderless Printing Width |
515mm (JIS B2), 1,030mm (JIS B0), 594mm (ISO A1), 841mm (ISO A0), 10", 14", 17", 24", 36", 42", 44" |
Paper Feed Method |
Roll Feed: One Roll, front output Front Loading Manual Feed: One sheet, front output |
Languages |
GARO (Canon Proprietary) |
Noise Level Approx |
Operation: 50 dB (A) or less Standby: 35 dB (A) or less Acoustic Power: Approx. 6.8 Bels or less |
Physical Dimensions |
45.0" (H) x 74.5" (W) x 28.9" (D) |
Weight |
Approximately 258lbs. with stand |
Power Source |
AC-100-240V (50-60Hz) |
Power Consumption |
Maximum: 190W or less Standby 5W or less Power Off: .5W or less (Compliant with Executive Order) |
Operating Environment |
Temperature: 59°-86° F (15°-30° C) Relative Humidity: 10-80% (No Condensation) |
User-replaceable items |
Print Head (PF-05), Maintenance Cartridge (MC-08), Durable Rotary Media Cutter (CT-06), Ink Tanks (PFI-306, PFI-706) |
Software Included |
Canon Printer Driver, Printer Driver Extra Kit (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), PosterArtist Lite (PC Only), Print Plug-in for Microsoft® Word/Excel/PowerPoint, Accounting Manager (PC Only), Direct Print & Share, Optimized Module for AutoCAD (PC Only) |
