| Projection Technology | RGB Liquid Crystal Shutter Projection System, Method: Front/Rear/Ceiling Mount, Driving Method: Poly Silicon TFT Active Matrix |
| LCD Size | 0.55” (D8) |
| Zoom Ratio | 1 - 1.2, Throw Ratio: 1.48 - 1.77 (Wide - Tele) |
| Image Size(Projected Distance) | 30” - 300” [0.9 - 9.0 m] |
| Projector Lens | No Optical Zoom / Focus (Manual), F Number: 1.58 - 1.72, Focal Length: 16.9 - 20.28 mm |
| Lamp Type | 200W UHE, Life : 5,000 hours in Normal Mode/ 10,000 hours in Eco Mode |
| Native Resolution | XGA (1024x768), Aspect Ratio: 4:3, 16:9 |
| Brightness | White: 2800 Lumens, Color: 2800 Lumens |
| Contrast Ratio | 15000:1 |
| Keystone | ±30° / ±30°, Correction: Yes (Vertical only) |
| Noise Level | 37dB / 28dB |
| Network | IEEE 802.11b: 11 Mbps, IEEE 802.11g: 54 Mbps, EEE 802.11n: 130 Mbps |
| Connectivity | D Sub 15pin (Blue) : 1 (Blue), Composite: RCA x 1 (Yellow), Component : D-Sub 15pin x 1 (Blue) (common with Analog RGB connector), S-Video : Mini DIN x 1, HDMI : 1 (HDCP Supported), USB Type A: 1 (USB Memory / ELPDC06 Document Camera / Wireless LAN adapto |
| Environment | 5 - 35 °C <41 - 95 °F> (0m / 0ft - 2,286m / 7,500ft) |
| Sound Output | 1W Monaural |
| Power | Power Supply Voltage : 100 - 240 V AC ±10%, 50/60 Hz, Power Consumption (Lamp on ) : 277W / 207W, Stand By (Network Off): 2.4W / 0.26W, Startup Period: About 5 seconds, Warm-up Period: 30 seconds, Direct Power On off : Yes, Cool Down Period : Instant Off |
| Dimension | 234 x 297 x 77 mm |
| Weight | 2.4 Kg/b> |
| Advanced Features | Security : WPA/WPA2-Personal (with optional Wireless LAN Unit) |
