Huntkey 550w Desktop Power Supply

 Huntkey 550w Desktop Power Supply Green Power

 Green power series power supply provides you an economical way to save energy, protect your environment and save  your money. It complies with Intel ATX12V Version 2.3 specifications. It includes 2 6+2 pin PCIE connector for high-  end graphic card and 4+4 pin connector (500W&550W) for Dual Core CPU and Multi Core CPU. Dual +12V rails  deliver safer and more reliable output to your system. The standby mode consumes less than 1W when +5VSB is less  than 0.1A. In addition, weve included a variety of industrial-grade protective circuitries: OCP (Over Current      Protection), OPP (Over Power Protection), OVP (Over Voltage Protection), SCP (Short Circuit Protection).

     * Features

•  Complies with Intel ATX12V V2.3
• Ultra low acoustic noise (?25dB)
•  The standby mode consumes less than 1W when +5VSB is less than 0.1A
• High reliability and built-in protection circuit OCP, OVP, OLP, SCP and line input fuse protection
• 100% Hi-pot and burn-in test

• MTBF: 100,000 hours at 25?

     * Specifications
       Input

• Rated: 450W

•  Peak: 550W

     * Voltage Specifications: 230VAC (180-264VAC)/ 115VAC (90-132VAC)

•  Voltage: +3.3V +5V +12V1 +12V2 -12V +5VSB
•  Max Load: 25.0A 20.0A 16.0A 18.0A 0.5A 2.5A
•  Min Load: 0.3A 0.5A 1.0A 1.0A 0.0A 0.0A
•  Regulation: 5% 5% 5% 5% 10% 5%
•  Ripple & Noise: 50mV 50mV 120mV 120mV 120mV 50mV
• PFC: Without PFC
